Jib Crane Models
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast which measures up to 20 feet long. Jib cranes can move loads between any areas within the boom's arc of rotation. Light duty units are used in factories and warehouses for loads weighing up to 5 tons. The web site BestJibCranes.com features the major kinds of jib cranes as being either wall-mounted, mast mounted or free-standing.
Free Standing
Free-standing jib cranes can stand alone not needing support from the building structure. The horizontal boom in this case is connected to a pivoting vertical column that is solidly anchored to the building floor. This type of jib crane can rotate a full 360 degrees and needs a foundation made of either steel or concrete.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the top and the bottom. These pivots are attached to the building floor and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the advantage of not needing the massive foundation needed for free-standing units.
Wall Mounted
Wall mounted jib cranes are connected to the wall of the building instead of supporting a normal vertical column. These cranes offer a horizontal boom. These machinery provide up to 200 degrees of rotation and are great in areas where the full 360 degree rotation is not required.
Depending on how the boom is supported, there are two model varieties. One type uses a tie rod from above the boom which is attached to the wall. The other type supports the boom from below by using a cantilever brace which is connected to the wall too.
